Car Wiring Diagrams for Electronic active headrest circuit for Hyundai Equus II (2009-2013)

ACTIVE HEADREST SENSOR MODULE (UNDER CENTER CONSOLE) AUDIO BLK WIRE BLU WIRE DATA LINK CONNECTOR DRIVER ACTIVE HEADREST (IN DRIVER'S SEAT BACK) E/R FUSE, RELAY BOX (LEFT SIDE OF ENGINE COMPT) FUSE GRN WIRE GRN/WHT WIRE GRY WIRE HOT IN ON OR START I/P-LHC IMPACT SENSOR J/C LEFT I/P JUNCTION BOX MULTIPURPOSE CHECK CONNECTOR PASSENGER ACTIVE HEADREST (IN FRONT PASSENGER'S SEAT BACK) RED WIRE WHT WIRE
