Hyundai Equus II (2009-2013) select shift Wiring diagram
This page shows the only wiring diagram for the component.select shift, which is found in the car Hyundai Equus II (2009-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram select shift (1 of 1)
ATM SOLENOID
B/UP LP RLY
BLK WIRE
BLU WIRE
C-CAN HIGH
C-CAN LOW
COMPUTER DATA LIGHTS SYSTEM
COMPUTER DATA LINES SYSTEM
CRANKING SIG
DOWN SHIFT
E/R JUNCTION BOX
E/R-CA
E/R-CB
ECU-B FUSE
GRN WIRE
GROUND
GROUND CTG-ZF
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
IPM (LEFT SIDE OF DASH)
J/C
K-KINE
MEMORY POWER
ON/START INPUT
ORG/ WIRE
ORG/BLK WIRE
P POSITION SWITCH
RED WIRE
RED/BLK WIRE
SELECT SHIFT
SELECT SW
SHIFT LOCK
SPORT MODE SWITCH
STARTING/CHARGING SYSTEM
TCM (LOWER RIGHT REAR OF TRANSMISSION)
TCU FUSE
U-DRMU
UP SHIFT
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Transmission circuit -> SELECT SHIFT
