Hyundai Equus II (2009-2013) rear rear console audio switch switch Wiring diagram

5:5 6:4 SEAT SEAT FRONT MONITOR A/C ANALOG CONTROL CLOCK MODULE A/CON (B+) FUSE A/V, NAVIGATION HEAD UNIT AUTO LIGHT SENSOR, SECURITY INDICATOR BATTERY BATTERY, BATTERY FUSE BOX BLK WIRE BLU WIRE BLU/RED WIRE BRN WIRE BS FUSE CTG-K CTG-ZF DRIVER POWER DOOR LATCH E/R BATT 1 FUSE E/R BATT 2 FUSE E/R-CA E/R-CB ECU FUSE ECU-B FUSE ELECTRONIC SNSR+ BATTERY LIN LINE SENSOR (NEGATIVE BATTERY) TERMINAL) ENGINE CONTROL RELAY FAM FAM POWER-1 FUSE FAM POWER-2 FUSE FAM-A FAM-C FROM BODY UNIT-1 FUSE (DIAGRAM 3 OF 10) AUDIO (B+) FUSE FROM P/CONN FUSE (DIAGRAM 3 OF 10) F/LID P/DOOR OPEN (FL) FUSE FUSE FUEL PUMP FUSE FUEL PUMP RELAY FUSE GRN WIRE GRN/BLK WIRE HEAD LAMP (LOW) RELAY I/P-LHA I/P-LHC I/P-LHD I/P-LHG JOINT BOX LEFT I/P JUNCTION BOX MEDIA MODULE MOTOR NCA WIRE ORG/ WIRE ORG/BLK WIRE PNK WIRE REAR CONSOLE SWITCH REAR MONITOR REAR REAR CONSOLE AUDIO SWITCH SWITCH RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RED/ORG WIRE RELAY RF RECEIVER ROOM LAMP RELAY ROOM LP FUSE TCM TERMINAL TO E/R FUSE, BODY RELAY BOX GROUND (DIAGRAM 3 OF 10) TO E/R FUSE, RELAY BOX (DIAGRAM 2 OF 10) TO P/DOOR (RL) FUSE (DIAGRAM 4 OF 10) WHT WIRE WHT/BLK WIRE YEL WIRE YEL/ORG WIRE
