Hyundai Elantra VII (2020-2024) Backup lamps circuit

B+2 FUSE BACKUP LAMP BACKUP LAMP GND BACKUP LAMP SWITCH BACKUP SIG BLK WIRE BLU WIRE COMPUTER DATA LINES SYSTEM CVT DCT E/R JUNCTION BLOCK E/R-A ECU 5 FUSE ELECTROCHROMIC MIRROR GRN WIRE HOT AT ALL TIMES HOT IN ON OR START ICU JUNCTION BLOCK ICU-A ICU-B ICU-C ICU-D ICU-E IPS 9 IPS 9 CTRL IPS CONTROL MODULE LEFT REAR COMBINATION LAMP (IN) M/T MULTI FUSE 1 NCA WIRE ON/START INPUT ORG/ WIRE ORG/BLK WIRE P-CAN HIGH P-CAN LOW P-CAN LOW TRANSAXLE RANGE SW P INPUT P-CAN P-CAN HIGH LOW PCB BLOCK PCM (2.0L) (LEFT SIDE OF ENGINE COMPT) PNK ON/START INPUT WIRE PNK WIRE POSITION SW POSITION SW CODE GND POSITION SW CODE PWR RIGHT REAR COMBINATION LAMP (IN) SHIFT LEVER "R" SW SIG 1 P SIG 2 (R) SIG 3 N SIG 4 D SW SIG 1 SW SIG 2 TCM (1.6L HYBRID) (TOP OF TRANSAXLE) TCU 2 FUSE TRANSAXLE RANGE SW D INPUT TRANSAXLE RANGE SW N INPUT TRANSAXLE RANGE SW R INPUT TRANSAXLE RANGE SWITCH YEL WIRE
