Hyundai Elantra VII (2020-2024) engine ctrl relay on i/p 74 3 engine ctrl relay ctrl Wiring diagram
This page shows the only wiring diagram for the component.engine ctrl relay on i/p 74 3 engine ctrl relay ctrl, which is found in the car Hyundai Elantra VII (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram engine ctrl relay on i/p 74 3 engine ctrl relay ctrl (1 of 1)
2.0L
BLDC (BRUSHLESS DC) MOTOR
BLK WIRE
BLU WIRE
BRN WIRE
CN7 1.6L TURBO
CN7 2.0L
COMPUTER DATA LINES SYSTEM
COOLING FAN 1 FUSE
COOLING FAN 1 RELAY
COOLING FAN 2 FUSE
COOLING FAN 2 RELAY
COOLING FAN HIGH RELAY CTRL
COOLING FAN LOW RELAY CTRL
COOLING FAN MOTOR (2.0L) (BEHIND RADIATOR)
COOLING FAN PWR CTRL
E/R JUNCTION BLOCK
E/R-A
E/R-D
ECTS 1 GND
ECTS 1 SIG
ECTS 2 GND
ECTS 2 SIG
ECU 2 FUSE
ECU 3 FUSE
ENGINE CONTROL RELAY
ENGINE COOLANT TEMPERATURE SENSOR 1
ENGINE COOLANT TEMPERATURE SENSOR 2
ENGINE CTRL RELAY ON I/P 74 3 ENGINE CTRL RELAY CTRL
FAN CONTROLLER COOLING
GRN WIRE
GRY WIRE
GRY/BLK WIRE
HOT AT ALL TIMES
HOT IN ON
ICU JUNCTION BLOCK
ICU-B
MEMORY PWR
MODULE 7 FUSE
MULTI FUSE 2
NCA WIRE
ORG/ WIRE
P-CAN HIGH
P-CAN LOW
PCB BLOCK
PCM (2.0L) ECM (1.6L TURBO) (LEFT SIDE OF ENGINE COMPT)
PWM SIG
RED WIRE
SENSOR 2 FUSE
WHT WIRE
YEL WIRE
YEL/ORG WIRE
Go to component -> Cooling fan circuit, except hybrid -> ENGINE CTRL RELAY ON I/P 74 3 ENGINE CTRL RELAY CTRL
