Car Wiring Diagrams for Forced entry circuit for Hyundai Elantra VI facelift (2018-2020)

B-CAN HIGH B-CAN LOW BLK WIRE BLU WIRE BLU/BLK WIRE BRN WIRE BURGLAR ALARM COMPUTER DATA LINES SYSTEM DOOR LOCK DOOR LOCK RELAY DOOR UNLOCK DOOR UNLOCK RELAY DR LK DR LOCK FUSE DR UNLK DRIVER DOOR LOCK ACTUATOR DRIVER DOOR MODULE (W/ MEMORY) DRIVER'S DOOR DRV DR DRV DR KEY GRN WIRE GRY WIRE GRY/BLK WIRE HOT AT ALL TIMES I/P-A I/P-B I/P-E I/P-F IPS CONTROL MODULE KEY LK KEY UNLK LEAK CURRENT AUTO CUT DEVICE LEFT REAR DOOR LOCK ACTUATOR LK/UNLK SIG LR DR MCU MEMORY 1 FUSE ORG/ WIRE PASSENGER DOOR MODULE (W/ MEMORY) PNK WIRE PNK/BLK WIRE RIGHT REAR DOOR LOCK ACTUATOR RLY CTRL RR DR - SMART JUNCTION BLOCK STARTING/ CHARGING SYSTEM SWITCH UNLK SIG W/ TWO TURN RELAY W/O TWO TURN RELAY WHT WIRE YEL WIRE

ADA AD BLK WIRE BLU WIRE BLU/BLK WIRE BRN WIRE BURGLAR ALARM DOOR LOCK DOOR LOCK DOOR UNLOCK DOOR LOCK SWITCH DOOR UNLOCK DR LK DR UNLK DRIVER'S DOOR DRV LK SW LK DRV LK SW UNLK DRV/PASS DR E/R JUNCTION BLOCK GRN WIRE GRY/BLK WIRE HOOD SW HOOD SWITCH HORN RLY CTRL HORNS SYSTEM I/P-B I/P-D I/P-F IPS CONTROL MODULE KEY LK KEY LK SIG KEY UNLK LK/UNLK SIG NCA WIRE ORG/ WIRE PASS DR PASS DR KEY PASSENGER DOOR LOCK ACTUATOR PASSENGER POWER WINDOW SWITCH PASSENGER'S DOOR PNK WIRE PNK/BLK WIRE POWER WINDOW MAIN SWITCH RED WIRE RLY CTRL SMART JUNCTION BLOCK TWO TURN TWO TURN UNLOCK RELAY UNLK SIG W/O MEMORY WHT WIRE YEL WIRE YEL/BLK WIRE YEL/ORG WIRE
