Hyundai Elantra V facelift (2013-2016) passenger weight classification sensor Wiring diagram
This page shows the only wiring diagram for the component.passenger weight classification sensor, which is found in the car Hyundai Elantra V facelift (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram passenger weight classification sensor (1 of 1)
2 WAY
8 WAY
BLK WIRE
BLK/GRN WIRE
BLK/RED WIRE
BRAKE FLUID LEVEL SENSOR
DRIVER DOOR SWITCH
DRIVER SEAT BELT BUCKLE SWITCH
DRIVER SEAT MANUAL SWITCH
DRIVER SEAT WARMER MODULE
GRN WIRE
GRY WIRE
JOINT
JOINT CONNECTOR
LEFT "C" PILLAR)
LEFT LEFT REAR REAR SEAT POWER WARMER WINDOW SWITCH SWITCH
LEFT LICENSE LAMP
LEFT REAR COMBINATION LAMP (OUT)
LEFT REAR DOOR LOCK ACTUATOR
LEFT REAR DOOR SWITCH
LEFT REAR SEAT WARMER
LEFT RIGHT REAR TRUNK REAR COMBINATION LID COMBINATION LAMP (IN) MOTOR LAMP (IN)
NCA WIRE
PASSENGER SEAT BELT BUCKLE SWITCH
PASSENGER WEIGHT CLASSIFICATION SENSOR
PDM 2 (ACC) RELAY
PDM 3 PDM 4 BLOWER RELAY RELAY RELAY
POWER WINDOW MAIN SWITCH
RIGHT LICENSE LAMP
SRS CONTROL MODULE
UDA DRIVER RECLINING LIMIT SWITCH
W/ POWER SEAT
W/ POWER W/O POWER SEAT SEAT
W/ SAFETY POWER WINDOWS
W/ SMART KEY
W/ SMART KEY W/ SMART KEY
W/O SAFETY POWER WINDOWS
WHT WIRE
WIPER MOTOR
YEL WIRE
Go to component -> Ground distribution circuit (2 of 3) -> PASSENGER WEIGHT CLASSIFICATION SENSOR
