Hyundai Elantra V facelift (2013-2016) ips control module trunk rly ctrl trunk op switch Wiring diagram
This page shows the only wiring diagram for the component.ips control module trunk rly ctrl trunk op switch, which is found in the car Hyundai Elantra V facelift (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ips control module trunk rly ctrl trunk op switch (1 of 1)
B-CAN
B-CAN TRANSCEIVER
BLK WIRE
COMPUTER DATA LINES SYSTEM
DOOR OPEN IND
FUEL CAP OPEN IND
GRN WIRE
HOT AT ALL TIMES
I/P-A
I/P-B
I/P-C
I/P-G
I/P-H
INSTRUMENT CLUSTER
INTERFACE
INTERIOR LAMP FUSE
IPS CONTROL MODULE TRUNK RLY CTRL TRUNK OP SWITCH
J/C UME
LEAK CURRENT AUTOCUT DEVICE
LEFT "C" PILLAR)
LOW HIGH
MEMORY FUSE
MICOM
MOTOR
ORG/ WIRE
RED WIRE
SMART JUNCTION BOX (UNDER LEFT END OF DASH)
TRUNK FUSE
TRUNK LID MOTOR
TRUNK OPEN IND
TRUNK RELAY
TRUNK ROOM LAMP
TRUNK ROOM LAMP SWITCH
Go to component -> Trunk release circuit -> IPS CONTROL MODULE TRUNK RLY CTRL TRUNK OP SWITCH
