Car Wiring Diagrams for Shift interlock circuit for Hyundai Elantra V (2010-2014)

A/T ACC/ON IN ATM KEY LOCK CONTROL MODULE (BEHIND LEFT CENTER OF DASH) ATM LEVER SWITCH (BELOW CENTER CONSOLE) ATM SOL ATM SOLENOID B/UP FUSE BLK WIRE BLU WIRE BLU/ORG WIRE BRN WIRE CLOCK FUSE CLUSTER FUSE CRUISE CONTROL MODULE (ON RIGHT FENDER) CRUISE CONTROL SYSTEM D INPUT E/R-CBG E/R-EROM ENGINE COMPARTMENT RELAY & FUSE BOX EXCEPT TOURING TOURING GRN WIRE GROUND GRY WIRE HOT AT ALL TIMES HOT IN ACC OR ON HOT IN ON OR START I/P-B I/P-C JOINT CONNECTOR KEY SOL KEY SOLENOID (STEERING COLUMN) ON/START IN ORG/ WIRE ORG/BLK WIRE P INPUT PARKING POSITION SW PARKING POSITION SWITCH PASSENGER COMPARTMENT JUNCTION BLOCK (UNDER LEFT SIDE OF DASH, NEAR KICK PANEL) PNK N INPUT WIRE PNK PNK WIRE PNK WIRE RED WIRE SNSR 2 FUSE STOP FUSE STOP LAMP STOP LAMP SWITCH SWITCH (ON BRAKE PEDAL BRACKET) TRANSAXLE RANGE SWITCH (ON TOP LEFT SIDE OF TRANSAXLE) TRANSMISSIONS SYSTEM VEHICLE SPD WHT WIRE YEL WIRE YEL/ORG WIRE
