Car Wiring Diagrams for Headlights circuit, with drl for Hyundai Elantra IV (2006-2011)

3 16 31 FRONT FOG LAMP RLY TAILLAMP RELAY CTRL HEADLAMP RELAY CTRL 9 6 7 FRONT FOG LAMP SW HEADLAMP SWITCH TAILLAMP SW INPUT B+ 1 FUSIBLE LINK BCM (BEHIND CENTER OF DASH) BLK WIRE BLU WIRE BRN WIRE DIMMER, PASSING SWITCH DRL RESISTOR (ON RIGHT FENDERWELL) E/R-EROM E/R-EROM E/R-FRT E/R-FRT ENGINE COMPARTMENT RELAY & FUSE BOX (IN LEFT FRONT CORNER OF ENGINE COMPT) FR FOG FUSE FRONT FOG LAMP RELAY FRONT FOG OFF LAMP SWITCH ON GRN WIRE GRN/ORG WIRE H/LP HI FUSE H/LP HI RELAY H/LP LO LH FUSE H/LP LO RELAY H/LP LO RH FUSE HEAD HOT AT ALL TIMES LEFT FRONT FOG LAMP LEFT HEADLAMP LIGHT SWITCH LO HI MULTI- FUNCTION SWITCH NCA WIRE ORG/ WIRE PARK OFF PNK WIRE RED WIRE RED/BLK WIRE RIGHT FRONT FOG LAMP RIGHT HEADLAMP WHT WIRE YEL WIRE

10 I/P-D 12 7 I/P-G 9 I/P-C ANTI-LOCK BRAKES SYSTEM BLK WIRE BLU WIRE BLU/BLK WIRE BLU/ORG WIRE BRN WIRE DIODE DRL CONTROL MODULE DRL FUSE FR FOG FRONT FOG IND FUSE GRN WIRE H/LP LO RELAY HEAD- LAMP HIGH BEAM IND HOT AT ALL TIMES HOT IN ON I/P-B I/P-C I/P-C 8 I/P-G 20 I/P-C I/P-D I/P-D 7 I/P-G I/P-D I/P-H INSTRUMENT CLUSTER INSTRUMENT CLUSTER SYSTEM ORG/ WIRE PARKING BRAKE SWITCH (ON BASE OF PARKING BRAKE LEVER) PASSENGER COMPARTMENT JUNCTION BLOCK (UNDER LEFT SIDE OF DASH, NEAR KICK PANEL) PNK WIRE RED WIRE RED/BLK WIRE RED/ORG WIRE SHUNT CONNECTOR STARTING/ CHARGING SYSTEM TAIL LAMP RELAY TAIL RH WHT WIRE YEL WIRE
