Car Wiring Diagrams for Shift interlock circuit for Hyundai Elantra III facelift (2003-2010)

A/T ACC/ON IN ATM KEY LOCK CONTROL MODULE (BEHIND LEFT CENTER OF DASH) ATM LEVER SWITCH (BELOW CENTER CONSOLE) ATM SOL ATM SOLENOID B/UP FUSE BLK WIRE BLU WIRE BLU/ORG WIRE BRN WIRE CLOCK FUSE CLUSTER FUSE CRUISE CONTROL MODULE (ON RIGHT FENDER) CRUISE CONTROL SYSTEM D INPUT E/R-CBG E/R-EROM ENGINE COMPARTMENT RELAY & FUSE BOX GRN WIRE GROUND GRY WIRE HOT AT ALL TIMES HOT IN ACC OR ON HOT IN ON OR START I/P JUNCTION BOX I/P-B I/P-C JOINT CONNECTOR KEY SOL KEY SOLENOID (RIGHT SIDE OF STEERING COLUMN) ON/START IN ORG/ WIRE ORG/BLK WIRE P INPUT PARKING POSITION SW PARKING POSITION SWITCH PNK N INPUT WIRE PNK PNK WIRE PNK WIRE RED WIRE SNSR 2 FUSE STOP FUSE STOP LAMP STOP LAMP SWITCH SWITCH (ON BRAKE PEDAL BRACKET) TRANSAXLE RANGE SWITCH (ON TOP LEFT SIDE OF TRANSAXLE) TRANSMISSIONS SYSTEM VEHICLE SPD WHT WIRE YEL WIRE
