Car Wiring Diagrams for Charging circuit for Hyundai Elantra III (2000-2003)

BATTERY BATTERY GROUND BODY GROUND BLK WIRE BLU WIRE CHARGE INDICATOR ENGINE COMPARTMENT RELAY & FUSE BOX FUSE 2 FUSIBLE LINK (BATT) FUSIBLE LINK ECU GENERATOR HEADLIGHTS SYSTEM HOT AT ON, START I/P-B I/P-H INSTRUMENT CLUSTER ORG/ WIRE PASSENGER COMPARTMENT JUNCTION BLOCK PRE- EXCITATION RESISTOR RED WIRE RED/ORG WIRE WHT WIRE
