Hyundai Elantra III (2000-2003) diag k-line opening ccv ctrl closing Wiring diagram
This page shows the only wiring diagram for the component.diag k-line opening ccv ctrl closing, which is found in the car Hyundai Elantra III (2000-2003). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram diag k-line opening ccv ctrl closing (1 of 1)
A/C SIG IN COOLING SIG IN
A/C SW ON IN SENSOR GND MAP SIG INJ 3 CTRL INJ 2 CTRL
A/T M/T
AIR CONDITIONING SYSTEM
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BRN WIRE
BRN/ORG WIRE
COOLING FANS SYSTEM
DATA LINK CONNECTOR (DLC) (LOWER LEFT OF STEERING COLUMN)
DIAG K-LINE OPENING CCV CTRL CLOSING
ENGINE CONTROL MODULE (ECM) (BELOW LEFT END OF DASH)
FUSE 10
FUSE 2
GND IAT SIG
GRN WIRE
GRN/BLK WIRE
GRY WIRE
HOT IN RUN OR START
I/P-H
IAT
INSTRUMENT CLUSTER
JOINT CONNECTOR
MANIFOLD ABSOLUTE PRESSURE SENSOR (TOP LEFT SIDE OF SURGE TANK)
MAP
MIL IND
MULTIPURPOSE CHECK CONNECTOR (LOWER LEFT OF STEERING COLUMN)
ORG/ WIRE
PASSENGER COMPARTMENT JUNCTION BLOCK (LEFT SIDE OF DASH)
RED WIRE
RED/BLK WIRE
RED/ORG WIRE
SENSOR GND
SENSOR SIG
TACHO- METER
TRANSMISSION CONTROL MODULE (BEHIND LEFT SIDE OF DASH)
WHT WIRE
YEL WIRE
YEL/BLK WIRE
YEL/ORG WIRE
Go to component -> Wiring diagram engine performance 2.0ls (3 of 3) -> DIAG K-LINE OPENING CCV CTRL CLOSING
