Hyundai Elantra III (2000-2003) data input/ output Wiring diagram
This page shows the only wiring diagram for the component.data input/ output, which is found in the car Hyundai Elantra III (2000-2003). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram data input/ output (1 of 1)
2 3 (M/T) (A/T)
ABS CONTROL MODULE (IN RIGHT FRONT CORNER OF ENGINE COMPARTMENT)
BLK WIRE
BRN WIRE
BRN/ORG WIRE
CHECK CONNECTOR
CODE SAVE
CRUISE CONTROL SYSTEM
DATA INPUT/ OUTPUT
DATA LINK CONNECTOR (DLC) (BELOW LEFT SIDE OF DASH)
DIAG
ENGINE COMPARTMENT RELAY & FUSE BOX
ENGINE CONTROL MODULE (ECM) (BEHIND LEFT SIDE OF DASH, ABOVE KICK PANEL)
ETACS CONTROL MODULE (UNDER CENTER OF DASH, BELOW RADIO)
FUEL PUMP RELAY
FUEL SENDER, FUEL PUMP MOTOR (INSIDE TOP OF FUEL TANK)
FUSE 25
GRN WIRE
GRN/BLK WIRE
GRY WIRE
GRY/ORG WIRE
HOT AT ALL TIMES
I/P-G
I/P-J
I/P-K
INSTRUMENT CLUSTER
JOINT
JOINT CONNECTOR
K LINE
MOTOR
NCA WIRE
ORG/ WIRE
PASSENGER COMPARTMENT JUNCTION BLOCK
PNK DIAG WIRE
PNK WIRE
RED WIRE
RED/BLK WIRE
SRS CONTROL MODULE (UNDER REAR CONSOLE)
TRANSAXLE CONTROL MODULE (TCM) (BEHIND LEFT SIDE OF DASH)
VEHICLE SPEED SENSOR (ON SPEEDOMETER HEAD)
YEL WIRE
Go to component -> Computer data lines -> DATA INPUT/ OUTPUT
