Hyundai Elantra III (2000-2003) chime bell control Wiring diagram
This page shows the only wiring diagram for the component.chime bell control, which is found in the car Hyundai Elantra III (2000-2003). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram chime bell control (1 of 1)
8 18 16 LEFT FRONT DOOR SWITCH DOOR SWITCH (ALL) GROUND
BLK WIRE
BLU WIRE
CHIME BELL (BEHIND LEFT SIDE OF DASH)
CHIME BELL CONTROL
DOOR AJAR IND
DOOR WARNING SWITCH INPUT
ETACS CONTROL MODULE (UNDER CENTER OF DASH)
FUSE 2
FUSE 25
GRN WIRE
HOT AT ALL TIMES
HOT IN ON OR START
I/P-G
I/P-H
IGNITION KEY ILLUMINATION, DOOR WARNING SWITCH
INSTRUMENT CLUSTER
J/C
LEFT FRONT DOOR SWITCH
LEFT REAR DOOR SWITCH
LIGHT SWITCH
MULTIFUNCTION SWITCH
NCA WIRE
ON/START INPUT
ORG/ WIRE
PARK HEAD OFF
PASSENGER COMPARTMENT JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
RED WIRE
RED/ORG WIRE
RIGHT FRONT DOOR SWITCH
RIGHT REAR DOOR SWITCH
SEAT BELT IND
SEAT BELT INDICATOR CTRL
SEAT BELT SWITCH
SEAT BELT SWITCH (IN DRIVER'S SEAT BELT BUCKLE)
SPEEDOMETER
TAILLIGHT RELAY AUTO CUT CNTRL
YEL WIRE
YEL/ORG WIRE
