Hyundai Elantra III (2000-2003) canister purge valve camshaft position sensor wiring diagram
This page shows the only wiring diagram for the component.canister purge valve camshaft position sensor, which is found in the car Hyundai Elantra III (2000-2003). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
canister purge valve camshaft position sensor wiring diagram (1 of 1)
A/C CONTROL MODULE
AUTO A/C
BLK WIRE
BLOWER MOTOR
BLOWER RELAY
CANISTER PURGE VALVE CAMSHAFT POSITION SENSOR
CRANKSHAFT POSITION SENSOR
DEFOGGER RELAY
DOOR LOCK CONTROL MODULE
FROM
FROM FUSIBLE LINK
FUSE 13
FUSE 15
FUSE 17
FUSE 4
FUSE 5
GRN WIRE
HAZARD RELAY
HAZARD SWITCH
HEATED OXYGEN SENSOR (DOWN)
HEATED OXYGEN SENSOR (UP)
HIGH BLOWER RELAY
I/P-A
I/P-C
I/P-D
I/P-F
I/P-F (NOT USED)
I/P-G
I/P-H
I/P-J
IDLE SPEED CONTROL ACTUATOR
INJECTOR 1
INJECTOR 2
INJECTOR 3
INJECTOR 4
INJECTOR FUSE
LEFT FRONT DOOR LOCK ACTUATOR
LEFT OUTSIDE MIRROR MOTOR, DEFOGGER ETACS (OR TACS) CONTROL MODULE
MANUAL A/C
NCA WIRE
PASSENGER COMPARTMENT RELAY BOX (BEHIND LEFT SIDE OF DASH)
REAR WINDOW DEFOGGER
RED WIRE
RIGHT OUTSIDE MIRROR MOTOR, DEFOGGER
SENSOR FUSE
SIREN
SUNROOF RELAY
TO TAILLIGHT RELAY (DIAGRAM 3 OF 5)
W/O ETACS CM
WHT WIRE
Go to component -> Power distribution circuit (2 of 5) -> CANISTER PURGE VALVE CAMSHAFT POSITION SENSOR
