Hyundai Elantra III (2000-2003) brake fluid level sensor vehicle speed sensor Wiring diagram
This page shows the only wiring diagram for the component.brake fluid level sensor vehicle speed sensor, which is found in the car Hyundai Elantra III (2000-2003). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram brake fluid level sensor vehicle speed sensor (1 of 1)
A/T
A/T CONTROL RELAY
ABS CONTROL MODULE
AQS SENSOR
BLK WIRE
BRAKE FLUID LEVEL SENSOR VEHICLE SPEED SENSOR
CENTER HORN
CONDENSER FAN MOTOR
CONDENSER FAN RELAY 2
CRUISE CLUTCH PEDAL POSITION SWITCH A/T SHIFT LEVER ILLUMINATION
CRUISE CONTROL MODULE FRONT WIPER MOTOR
DRL CONTROL MODULE
ENGINE COMPARTMENT RELAY & FUSE BOX
LEFT FRONT TURN SIGNAL LAMP LEFT SIDE REPEATER LAMP
LEFT HEAD- LAMP
M/T
NCA WIRE
REAR WIPER MOTOR CONTROL MODULE
RELAY
RIGHT FRONT TURN SIGNAL LAMP
RIGHT HEAD- LAMP
RIGHT SIDE MARKER LAMP
TCM
VEHICLE SPEED SENSOR
WIPER MOTOR RELAY
Go to component -> Ground distribution circuit (3 of 3) -> BRAKE FLUID LEVEL SENSOR VEHICLE SPEED SENSOR
