Hyundai Elantra III (2000-2003) 4 2 1 3 acc/on input memory pwr dim input ground Wiring diagram

4 2 1 3 ACC/ON INPUT MEMORY PWR DIM INPUT GROUND A/T BLK WIRE BLU WIRE BLU/BLK WIRE BRAKE FLUID LEVEL SENSOR (IN BRAKE FLUID RESERVOIR) BRN/ORG WIRE DIGITAL CLOCK DIODE ECM (LEFT SIDE OF DASH) FUEL SENDER FUEL TANK FUSE 10 FUSE 25 FUSE 9 GAUGE SENDER GRY WIRE GRY/ORG WIRE HOT AT ACC OR ON HOT AT ALL TIMES HOT AT ON OR START I/P-F I/P-G I/P-H M/T M/T A/T 1 2 3 2 3 1 NCA WIRE PARKING BRAKE SWITCH (AT BASE OF PARKING BRAKE LEVER) PASSENGER COMPARTMENT JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH) PNK WIRE RED WIRE TACS CONTROL MODULE (CENTER OF DASH) THERMISTOR VEHICLE SPEED SENSOR (ON TRANSAXLE) YEL WIRE
