Anti-lock brake circuits for Hyundai Elantra II (1995-1998)

2 2 (GL) (GLS) 6 6 (GL) (GLS) ABS FUSE 11 ABS MODULATOR (RIGHT REAR OF ENGINE COMPARTMENT) ABS PUMP MOTOR (RIGHT FRONT OF ENGINE COMPARTMENT) ABS PUMP MOTOR RELAY ABS RELAY BOX (FRONT OF ENGINE COMPARTMENT) ANTILOCK BRAKE CONTROL MODULE (TRUNK COMPARTMENT, INSIDE RIGHT REAR FENDER) BLK WIRE BLK/BLU WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/BLK WIRE BLU/RED WIRE BRAKE PEDAL SWITCH (BRAKE PEDAL SUPPORT) BRN WIRE DASH FUSE BOX DATA LINK CONNECTOR (LEFT SIDE OF I/P) ENGINE COMPARTMENT FUSE/RELAY BOX (RIGHT FRONT OF ENGINE COMPT) ETACS,CLUSTER FUSE 10 FAIL SAFE RELAY FUSE 4 FUSIBLE LINK D (ABS) FUSIBLE LINK J (ABS) PNK WIRE GRN WIRE GRN/WHT WIRE GRN/YEL WIRE HOT AT ALL TIMES HOT IN ON OR START INSTRUMENT CLUSTER ABS IND LEFT FRONT SOL LEFT FRONT WHEEL SENSOR LEFT REAR SOL LEFT REAR WHEEL SENSOR RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE RIGHT FRONT SOL RIGHT FRONT WHEEL SENSOR RIGHT REAR SOL RIGHT REAR WHEEL SENSOR TAN WIRE WHT WIRE WHT/BLK WIRE WHT/BLU (OR WHT/RED) WIRE WHT/BLU WIRE WHT/GRN (OR BLK/BLU) WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/RED WIRE YEL/WHT WIRE
