Hyundai Elantra II (1995-1998) rear window defogger switch cruise switch Wiring diagram
This page shows the only wiring diagram for the component.rear window defogger switch cruise switch, which is found in the car Hyundai Elantra II (1995-1998). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear window defogger switch cruise switch (1 of 1)
10 11 (GLS) (GL)
A/C SWITCH
ASHTRAY ILLUMINATION
ASHTRAY ILLUMINATION CIGARETTE LIGHTER ILLUMINATION
BLOWER RELAY
BLU/BLK WIRE
BLU/WHT WIRE
CIGARETTE LIGHTER ILLUMINATION
COMBINATION SWITCH
CRUISE CONTROL MODULE CRUISE CONTROL MAIN SWITCH
CRUISE SWITCH REAR WINDOW DEFOGGER SWITCH
DIGITAL CLOCK
ENGINE COMPARTMENT FUSE/RELAY BOX
FROM FUSE 16 (DIAGRAM 3 OF 5)
FROM LEFT T/LP FUSE (DIAGRAM 2 OF 5)
FROM TAIL 1 RELAY (DIAGRAM 2 OF 5)
GRN WIRE
GRN/WHT WIRE
GRN/YEL WIRE
H/LP RELAY
HAZARD SWITCH
HEATER AND A/C CONTROL PANEL
I/P DIMMER SWITCH
INSTRUMENT CLUSTER
INSTRUMENT CLUSTER RADIO
POWER WINDOW RELAY
RADIO
REAR WINDOW DEFOGGER SWITCH CRUISE SWITCH
REAR WIPER/ WASHER SWITCH
RED WIRE
RED/WHT WIRE
RED/YEL WIRE
SEDAN
SHIFT INDICATOR
SHIFT INDICATOR INSTRUMENT CLUSTER
SUNROOF CLOSE/TILT UP RELAY
SUNROOF OPEN/TILT DOWN RELAY
WAGON
WHT/GRN WIRE
Go to component -> Power distribution circuit (4 of 5) -> REAR WINDOW DEFOGGER SWITCH CRUISE SWITCH
