Hyundai Elantra II (1995-1998) left rear tail light left tail/stop light Wiring diagram
This page shows the only wiring diagram for the component.left rear tail light left tail/stop light, which is found in the car Hyundai Elantra II (1995-1998). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left rear tail light left tail/stop light (1 of 1)
4 2 (W/ CRUISE) (W/O CRUISE)
ANTI- LOCK BRAKE CONTROL MODULE (RIGHT SIDE OF CARGO COMPARTMENT)
ANTI-THEFT CONTROL MODULE (OPTIONAL) (BEHIND LEFT SIDE OF DASH)
ANTI-THEFT SYSTEM
BLK WIRE
BRAKE PEDAL SWITCH (ON SUPPORT BRACKET)
BRN WIRE
COMBINATION SWITCH
CRUISE CONTROL MODULE (BELOW RADIO)
DASH FUSE BOX
DIGITAL CLOCK
ENGINE COMPARTMENT FUSE/RELAY BOX
EXTERIOR LIGHTS CONTROL
FUSIBLE LINK G
GRN WIRE
GRN/BLU WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HIGH MOUNT STOP LIGHT
HOT AT ALL TIMES
LEFT FRONT PARK/TURN LIGHT
LEFT LICENSE LIGHT
LEFT REAR TAIL LIGHT LEFT TAIL/STOP LIGHT
LEFT TAIL LAMP FUSE
LEFT TAIL/STOP LIGHT
LIGHT SWITCH
NCA WIRE
OFF HEAD PARK
PNK WIRE
RED WIRE
RED/BLU WIRE
RIGHT FRONT PARK/TURN LIGHT
RIGHT LICENSE LIGHT
RIGHT REAR TAIL LIGHT
RIGHT TAIL LAMP FUSE
RIGHT TAIL/ STOP LIGHT
STOP LP FUSE 3
TAIL 1 RELAY
TRAN- SAXLE AND KEY LOCK CONTROL MODULE (LEFT SIDE OF I/P)
YEL WIRE
Go to component -> Exterior lamps circuit, sedan (1 of 2) -> LEFT REAR TAIL LIGHT LEFT TAIL/STOP LIGHT
