Hyundai Elantra II (1995-1998) intermittent/ delay input Wiring diagram
This page shows the only wiring diagram for the component.intermittent/ delay input, which is found in the car Hyundai Elantra II (1995-1998). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram intermittent/ delay input (1 of 1)
BLK WIRE
BLK/RED WIRE
BLK/YEL WIRE
BLU WIRE
BLU/GRN WIRE
BLU/RED WIRE
BLU/WHT WIRE
BLU/YEL WIRE
COMBINATION SWITCH (LEFT SIDE OF STEERING COLUMN)
DASH FUSE BOX (BELOW LEFT SIDE OF DASH)
DASH)
DELAY CONTROL
ELECTRONIC TIME AND ALARM CONTROL MODULE (BEHIND CENTER OF
FRONT WASHER MOTOR (BOTTOM OF WINDSHIELD WASHER FLUID RESERVOIR)
FRONT WIPER MOTOR (LEFT REAR CORNER OF ENGINE COMPARTMENT)
GRN WIRE
GRN/BLK WIRE
HI OFF
HOT IN ON WIPER, ETACS, WASHER FUSE 8
INTERMITTENT INPUT
INTERMITTENT/ DELAY INPUT
LO INT
MOTOR
OFF/INT INPUT
ORG/ WIRE
PARK SWITCH
PARK SWITCH INPUT
POWER
RED WIRE
WAGON SEDAN
WASH
WASH INPUT
WIPER/WASHER SWITCH
YEL WIRE
Go to component -> Front wiper/washer circuit -> INTERMITTENT/ DELAY INPUT
