Hyundai Elantra II (1995-1998) indicators charge warning indicator Wiring diagram
This page shows the only wiring diagram for the component.indicators charge warning indicator, which is found in the car Hyundai Elantra II (1995-1998). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram indicators charge warning indicator (1 of 1)
12 2 (GL) (GLS)
B/UP LP, T/SIG LP FUSE 9
BATTERY
BLK WIRE
BLU WIRE
DASH FUSE BOX
ELECTRONIC TIME, ALARM CONTROL MODULE (UNDER DRIVER'S SEAT)
ENGINE COMPARTMENT FUSE/RELAY BOX
ETACS CLUSTER FUSE 10
FUSIBLE LINK A (ALT)
FUSIBLE LINK C (ECU)
HOT IN ON OR START
IG GENERATOR
INDICATORS
INDICATORS CHARGE WARNING INDICATOR
INSTRUMENT CLUSTER
LT GRN WIRE
PRE- EXCITATION RESISTOR
RED/WHT WIRE
STARTING SYSTEM (STARTER SOLENOID)
TRANSAXLE
WHT WIRE
WHT/YEL WIRE
YEL WIRE
Go to component -> Charging circuit -> INDICATORS CHARGE WARNING INDICATOR
