Hyundai Elantra II (1995-1998) ground inter in power off/int in Wiring diagram
This page shows the only wiring diagram for the component.ground inter in power off/int in, which is found in the car Hyundai Elantra II (1995-1998). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ground inter in power off/int in (1 of 1)
BLK WIRE
BLK/GRN WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BLK WIRE
BLU/RED WIRE
BLU/RED(OR WHT/RED) WIRE
BLU/YEL WIRE
BRN WIRE
BRN/WHT WIRE
BURG ALARM B+ FUSE
CHIME BELL (UPPER LEFT SIDE OF DASH)
DASH FUSE BOX
DEFOGGER SYSTEM
DOOR WARNING SWITCH
ELECTRONIC TIME AND ALARM CONTROL MODULE (BELOW RADIO)
ENGINE COMPARTMENT FUSE/RELAY BOX
ETACS CLUSTER FUSE 10
ETACS WIPER FUSE 8
GENERATOR
GRN WIRE
GRN/BLK WIRE
GROUND INTER IN POWER OFF/INT IN
HOT AT ALL TIMES
HOT IN ON
HOT IN ON OR START
INSTRUMENT CLUSTER SYSTEM
LEFT FRONT DOOR JAMB SWITCH
NCA WIRE
REAR DEFOG RQST GROUND DEFOG RLY CTRL
RED/BLK WIRE
RED/YEL WIRE
STARTING/CHARGING SYSTEM
WHT/YEL WIRE
WIPER/WASHER SYSTEM
WIPER/WASHER SYSTEM WARNING SYSTEM
WIPER/WASHER SYSTEM WIPER/WASHER SYSTEM
Go to component -> Body computer circuits -> GROUND INTER IN POWER OFF/INT IN
