Hyundai Elantra II (1995-1998) audio fuse 14 clock fuse 3 Wiring diagram
This page shows the only wiring diagram for the component.audio fuse 14 clock fuse 3, which is found in the car Hyundai Elantra II (1995-1998). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram audio fuse 14 clock fuse 3 (1 of 1)
11 7 (GLS) (GL)
A/T
ABS FUSE 11
ABS RELAY BOX
AIR BAG FUSE 12
ANTI-LOCK BRAKE CONTROL MODULE
AUDIO FUSE 14 CLOCK FUSE 3
B/UP LP FUSE 9
BACK-UP LIGHT SWITCH
BLK/GRN WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU/BLK WIRE
BLU/RED WIRE
BLU/WHT WIRE
BLU/YEL WIRE
CIGARETTE LIGHTER
CRUISE CONTROL MODULE
DASH FUSE BOX
ECT FUSE 15
ENGINE COMPARTMENT FUSE/RELAY BOX
ENGINE CONTROL MODULE
ETACS FUSE 10
ETACS MODULE
FROM FUSIBLE LINK F (DIAGRAM 2 OF 5)
GRN/RED WIRE
GRN/YEL WIRE
H/LP FUSE 16
HAZARD SWITCH
IGNITION COIL ASSEMBLY
IGNITION SWITCH
INSTRUMENT CLUSTER
LOCK
LT GRN/YEL WIRE
M/T
M/T A/T
NCA WIRE
OVER DRIVE SWITCH
POWER CONNECTOR
POWER MIRROR SWITCH INSTRUMENT CLUSTER
PRE- EXCITATION RESISTOR ENGINE COMPARTMENT FUSE/RELAY BOX
RADIO
RED/WHT WIRE
RELAY ENGINE COMPARTMENT FUSE/RELAY BOX
SRS CONTROL MODULE
TO FUSE 8
TO H/LP RELAY (DIAGRAM 4 OF 5)
TRANS- AXLE RANGE SWITCH
TRANSAXLE AND KEY LOCK CONTROL MODULE
TRANSAXLE CONTROL MODULE
TRANSAXLE RANGE SWITCH
TRANSAXLE SHIFT MODE SWITCH
WHT/BLK WIRE
WHT/BLU WIRE
YEL/BLK WIRE
YEL/RED WIRE
Go to component -> Power distribution circuit (3 of 5) -> AUDIO FUSE 14 CLOCK FUSE 3
