Hyundai Azera II facelift (2014-2017) roller blind switch Wiring diagram
This page shows the only wiring diagram for the component.roller blind switch, which is found in the car Hyundai Azera II facelift (2014-2017). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram roller blind switch (1 of 1)
BLK WIRE
BLU WIRE
BLU/BLK WIRE
CLOSE SWITCH
CRUISE CONTROL SYSTEM
GLASS STATUS SIGNAL
GLASS SWITCH
GRN WIRE
GRN/ORG WIRE
GROUND
HOT AT ALL TIMES
I/P-D
I/P-E
IPS CONTROL BLOCK
MEMORY POWER
OPEN SWITCH
ORG/ WIRE
OVERHEAD CONSOLE LAMP SWITCH
PANORAMA SUNROOF
PNK WIRE
ROLLER BLIND MOTOR, SLAVE CONTROL
ROLLER BLIND SWITCH
SMART JUNCTION BLOCK
SPEED SIGNAL B+ BLIND CLOSE SWITCH BLIND OPEN SWITCH GROUND
SUNROOF FUSE
SUNROOF MOTOR, CONTROL
T/UP SWITCH
TILT UP SWITCH
VEHICLE SPEED
YEL WIRE
Go to component -> Power top/sunroof circuit -> ROLLER BLIND SWITCH
