Hyundai Azera II facelift (2014-2017) power supply c-can transceiver Wiring diagram
This page shows the only wiring diagram for the component.power supply c-can transceiver, which is found in the car Hyundai Azera II facelift (2014-2017). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram power supply c-can transceiver (1 of 1)
"ON"
B- B- C- C- CAN CAN CAN CAN HIGH LOW HIGH LOW
BLK WIRE
BLK/ORG WIRE
BRN WIRE
C-CAN HIGH
C-CAN LOW
CLUSTER
COMPUTER DATA LINES SYSTEM
DISTRIBUTION
GRN WIRE
GROUND
HOT AT ALL TIMES
HOT IN ON OR START
I/P-A
I/P-D
I/P-E
INPUT
INSTRUMENT
IPS CONTROL MODULE
LEAK CURRENT AUTO CUT DEVICE
LEFT "C" PILLAR)
LEFT FRONT TIRE PRESSURE SENSOR
LEFT REAR TIRE PRESSURE SENSOR
MEMORY
MEMORY 1 FUSE
MEMORY POWER
MICOM
MODULE 1 FUSE
MONO TFT LCD
ON/START INPUT
ORG/ WIRE
PNK/BLK WIRE
POWER
POWER DISTRIBUTION SYSTEM
POWER SUPPLY
POWER SUPPLY C-CAN TRANSCEIVER
RED/BLK WIRE
RIGHT FRONT TIRE PRESSURE SENSOR
RIGHT REAR TIRE PRESSURE SENSOR
SMART JUNCTION BLOCK
SYSTEM
TIRE PRESSURE MONITORING MODULE
TPMS TREAD IND
WHT WIRE
YEL WIRE
Go to component -> Tire pressure monitoring circuit -> POWER SUPPLY C-CAN TRANSCEIVER
