Hyundai Azera II facelift (2014-2017) high- mounted stop lamp filter wiring diagram
This page shows the only wiring diagram for the component.high- mounted stop lamp filter, which is found in the car Hyundai Azera II facelift (2014-2017). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
high- mounted stop lamp filter wiring diagram (1 of 1)
BACKUP LAMP
BACKUP LAMPS CIRCUIT
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BRK LIGHT SW ELG-A
BRK SW
BRK SW SIG
BRK TEST SW
BRN WIRE
BRN/BLK WIRE
CIRCUIT
CONTROL
E/R JUNCTION BLOCK
ESC MODULE
GRN WIRE
GRY WIRE
GRY/BLK WIRE
HAC SIG
HIGH MOUNTED STOP LAMP
HIGH- MOUNTED STOP LAMP FILTER
HOT AT ALL TIMES
I/P-C
I/P-D
INPUT
INTERNAL
IPS
IPS CONTROL MODULE
LEFT REAR COMBINATION LAMP (IN)
LICENSE LAMP
LICENSE LAMP, TRUNK LID HANDLE SWITCH
MEMORY PWR
PCM
PNK WIRE
RED WIRE
RH LH
RIGHT REAR COMBINATION LAMP (IN)
RIGHT REAR COMBINATION LAMP (OUT)
SIDE MARKER LAMP
SMART JUNCTION BLOCK
SMART KEY CONTROL MODULE
STOP LAMP
STOP LAMP FUSE
STOP LAMP SWITCH
STOP SIGNAL ELECTRONIC MODULE
STP LMP
STP LMP SW
TAIL LAMP
TURN LAMP
WHT WIRE
YEL WIRE
Go to component -> Exterior lamps circuit (2 of 2) -> HIGH- MOUNTED STOP LAMP FILTER
