Hyundai Azera II (2011-2014) switch license lamp, trunk handle switch Wiring diagram
This page shows the only wiring diagram for the component.switch license lamp, trunk handle switch, which is found in the car Hyundai Azera II (2011-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram switch license lamp, trunk handle switch (1 of 1)
26 25 HIGH LOW
B-CAN
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BRN WIRE
BRN/ORG WIRE
CAN TRANSCEIVER IC
COMPUTER DATA LINES SYSTEM
DRIVER DOOR MODULE
FUEL FILLER ACTUATOR (LEFT SIDE OF TRUNK)
FUEL FILLER DOOR SWITCH
FUEL FILLER DOOR, TRUNK LID SWITCH
GRN WIRE
GRN/ORG WIRE
HOT AT ALL TIMES
I/P-A
I/P-D
I/P-E
I/P-F
ILL
INTERIOR LAMP FUSE
IPS CONTROL MODULE
LEAK CURRENT AUTOCUT DEVICE
LEFT "C" PILLAR)
MCU
MOTOR PTC
ORG/ WIRE
PNK WIRE
PNK/BLK WIRE
SMART JUNCTION BOX
SWITCH LICENSE LAMP, TRUNK HANDLE SWITCH
TRUNK FUSE
TRUNK LID
TRUNK LID HANDLE
TRUNK LID HANDLE SWITCH
TRUNK LID MOTOR (CENTER REAR OF
TRUNK LID RELAY
TRUNK LID SWITCH
TRUNK MAIN SWITCH
TRUNK ROOM LAMP
TRUNK ROOM LAMP SWITCH
W/O REAR CAMERA
WHT WIRE
WHT/ORG WIRE
YEL/ORG WIRE
Go to component -> Trunk, tailgate, fuel door circuit -> SWITCH LICENSE LAMP, TRUNK HANDLE SWITCH
