Hyundai Azera II (2011-2014) lin diagnostic data line Wiring diagram
This page shows the only wiring diagram for the component.lin diagnostic data line, which is found in the car Hyundai Azera II (2011-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram lin diagnostic data line (1 of 1)
APS 2 POWER
BLK WIRE
BLU WIRE
BRN WIRE
C/FAN RELAY LOW
CCV
CHARGING SYSTEM
CLG-B
CLGINJ-B
COOLING
CVVT EXHAUST BANK 1
CVVT EXHAUST BANK 2
CVVT INTAKE BANK 1
CVVT INTAKE BANK 2
ELG-A
ENG CTRL RLY CTRL
ENG CTRL RLY ON IN
ETC MOTOR (LOW)
FANS SYSTEM
FPRV CONTROL
FUEL PUMP RLY CTRL
GRN WIRE
GRN/BLK WIRE
GRY WIRE
IGNITION COIL CTRL 2
IGNITION COIL CTRL 4
IGNITION COIL CTRL 6
INJECTOR CONTROL 1
INJECTOR CONTROL 2
INJECTOR CONTROL 3
INJECTOR CONTROL 4
INJECTOR CONTROL 5
INJECTOR CONTROL 6
LIN DIAGNOSTIC DATA LINE
NCA WIRE
ORG/ WIRE
OXY SNSR 1 HEATER
OXY SNSR 2 HEATER
OXY SNSR 3 HEATER
OXY SNSR 4 HEATER
PCM (LEFT REAR OF ENGINE COMPT)
PNK WIRE
RED WIRE
START OVER RUN
STARTING/
WHT WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 3.3l (2 of 7) -> LIN DIAGNOSTIC DATA LINE
