Hyundai Azera II (2011-2014) b- b- c- can can can can low high low high Wiring diagram
This page shows the only wiring diagram for the component.b- b- c- can can can can low high low high, which is found in the car Hyundai Azera II (2011-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram b- b- c- can can can can low high low high (1 of 1)
"ON"
1 4 5 2 6 ON/START INPUT MEMORY POWER C-CAN HIGH C-CAN LOW
B- B- C- CAN CAN CAN CAN LOW HIGH LOW HIGH
BLK WIRE
BLK/ORG WIRE
BRN WIRE
C-CAN TRANSCEIVER
COMPUTER DATA LINES SYSTEM
GRN WIRE
GROUND
HOT AT ALL TIMES
HOT IN ON
HOT IN ON OR START
I/P-A
I/P-D
I/P-E
INPUT
INSTRUMENT CLUSTER
J/B
LEAK CURRENT AUTOCUT DEVICE
LEFT "C" PILLAR)
LEFT FRONT TIRE PRESSURE SENSOR
LEFT REAR TIRE PRESSURE SENSOR
MEMORY
MEMORY 1 FUSE
MICOM
MODULE 1 FUSE
MODULE 3 FUSE
MONO TFT LCD
ORG/ WIRE
PNK/BLK WIRE
POWER
POWER SUPPLY
RED/BLK WIRE
RIGHT FRONT TIRE PRESSURE SENSOR
RIGHT REAR TIRE PRESSURE SENSOR
SMART JUNCTION BOX
TIRE PRESSURE MONITORING MODULE
TPMS TREAD IND
WHT WIRE
YEL WIRE
Go to component -> Tire pressure monitoring circuit -> B- B- C- CAN CAN CAN CAN LOW HIGH LOW HIGH
