Hyundai Azera I (2005-2011) left mirror sensor Wiring diagram
This page shows the only wiring diagram for the component.left mirror sensor, which is found in the car Hyundai Azera I (2005-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left mirror sensor (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
DEFOGGER
DEFOGGER SYSTEM
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON
I/P-J
I/P-K
INPUT CIRCUIT
JOINT CONNECTOR D-1 (IN LEFT FRONT DOOR)
JOINT CONNECTOR D-2 (IN RIGHT FRONT DOOR)
JOINT CONNECTOR F-1 (ON LEFT "C" PILLAR)
JOINT CONNECTOR F-4
LEFT MIRROR SENSOR
MCU
MEMORY FUSE
MIRROR CONTROL IC
MODULE 1 FUSE
NCA WIRE
ORG/ WIRE
PASSENGER COMPARTMENT JUNCTION BLOCK (UNDER LEFT END OF DASH)
POWER WINDOW MAIN SWITCH
RED WIRE
REGULATOR IC
RIGHT FRONT POWER WINDOW SWITCH
RIGHT MIRROR SENSOR
YEL WIRE
Go to component -> Power mirrors circuit, without fold-back mirrors -> LEFT MIRROR SENSOR
