Hyundai Avante VII (2020-2024) Ground distribution circuit, except hybrid cn7

A/C CONTROL MODULE A/C CONTROLLER A/T SHIFT LEVER INDICATOR AUTOMATIC A/C BLK WIRE BLK/WHT WIRE BLK/YEL WIRE CLOCKSPRING CRASH PAD SWITCH CVT CVT, DCT CVT/DCT DATA LINK CONNECTOR DCT DRIVE MODE SWITCH DRIVER MOOD LAMP ELECTRO- CHROMIC MIRROR FRONT CONSOLE SWITCH FRONT POWER OUTLET FRONT USB CHARGER FRONT WIRELESS CHARGER HAZARD SWITCH ICU JUNCTION BLOCK IPS CONTROL MODULE IGNITION KEY ILLUMINATION, DOOR WARNING SWITCH INSTRUMENT CLUSTER JOINT CONNECTOR URA LANE KEEPING ASSIST UNIT LEFT FRONT MODE SWITCH LEFT FRONT VANITY LAMP M/T MANUAL A/C MOOD LAMP UNIT MULTI- FUNCTION SWITCH NCA WIRE OVERHEAD CONSOLE LAMP PARKING COLLISION AVOIDANCE ASSIST UNIT PNK WIRE RIGHT FRONT MODE SWITCH RIGHT FRONT VANITY LAMP ROOM LAMP SPORT MODE SWITCH STEERING WHEEL HEATER MODULE STEERING WHEEL) SUNROOF MOTOR W/ WIRELESS CHARGER W/O ISG W/O WIRELESS CHARGER

2.0L A/C PWM MODULE A/V, NAVIGATION HEAD UNIT AUDIO BLE UNIT BLK WIRE BLK/ORG WIRE BLK/WHT WIRE BLK/YEL WIRE BRN WIRE CENTER DOOR LOCK RELAY CENTER DOOR UNLOCK RELAY CVT, DCT DC-DC CONVERTER DRIVER DOOR LOCK ACTUATOR DRIVER DOOR NFC MODULE DRIVER POWER OUTSIDE MIRROR DRIVER SAFETY POWER WINDOW MODULE DRIVER SEAT MANUAL SWITCH DRIVER SMART KEY OUTSIDE HANDLE DRIVER'S DOOR FRONT MONITOR FRONT WIRELESS CHARGER FUEL PUMP CONTROL MODULE FUEL SENDER, FUEL PUMP MOTOR IAU IBU ICU-A ICU-C IPS CONTROL MODULE LEFT MIC (SHIELD) LEFT REAR DOOR LOCK ACTUATOR LEFT REAR POWER WINDOW SWITCH M/T MDPS UNIT NCA WIRE ORG BLK WIRE ORG/ WIRE POWER OUTSIDE MIRROR SWITCH POWER WINDOW MAIN SWITCH PTC HEATER RIGHT MIC (SHIELD) START STOP BUTTON SWITCH TWO TURN UNLOCK RELAY USB JACK W/ AMP W/ AUTO UP DOWN, SAFETY W/ ISG W/ NAVIGATION W/ NFC W/ REAR SEAT WARMER W/O AMP W/O NAVIGATION W/O NFC

AMP BLK WIRE BLK/ORG WIRE BLK/WHT WIRE BRN WIRE DRIVER SEAT BELT BUCKLE SENSOR FRONT SEAT WARMER CONTROL MODULE GRN WIRE HIGH MOUNTED STOP LAMP LEFT BLIND-SPOT COLLISION WARNING UNIT LEFT LICENSE LAMP LEFT PARKING DISTANCE WARNING REVERSE SENSOR LEFT PARKING DISTANCE WARNING- REVERSE SENSOR (CENTER) LEFT REAR COMBINATION LAMP (IN) LEFT REAR COMBINATION LAMP (OUT) NCA WIRE PASSENGER DOOR LOCK ACTUATOR PASSENGER DOOR NFC MODULE PASSENGER OCCUPANT DETECTION SENSOR PASSENGER POWER OUTSIDE MIRROR PASSENGER POWER WINDOW SWITCH PASSENGER SEAT BELT BUCKLE SENSOR PASSENGER SEAT MANUAL SWITCH PASSENGER SMART KEY OUTSIDE HANDLE PASSENGER'S DOOR REAR SEAT WARMER CONTROL MODULE RIGHT BLIND-SPOT COLLISION WARNING UNIT RIGHT LICENSE LAMP RIGHT PARKING DISTANCE WARNING REVERSE SENSOR RIGHT PARKING DISTANCE WARNING- REVERSE SENSOR (CENTER) RIGHT REAR COMBINATION LAMP (IN) RIGHT REAR COMBINATION LAMP (OUT) RIGHT REAR DOOR LOCK ACTUATOR RIGHT REAR POWER WINDOW SWITCH SGA SRS CONTROL MODULE TRUNK LID HANDLE SWITCH TRUNK LID LATCH W/ NFC W/O NFC

2.0L A/C RELAY ABS CONTROL MODULE BACKUP LAMP SWITCH BLK WIRE BLK/ORG WIRE BLOWER RELAY BRAKE FLUID LEVEL SENSOR COOLING FAN CONTROLLER COOLING FAN MOTOR CRANKSHAFT POSITION SENSOR SHIELD E/R JUNCTION BLOCK E/R-C ELECTRONIC OIL PUMP ESC CONTROL MODULE EXTERNAL BUZZER FORWARD COLLISION AVOIDANCE ASSIST UNIT FRONT WIPER (LOW) RELAY FRONT WIPER MOTOR HOOD SWITCH HORN (HIGH) HORN (LOW) IGNITION LOCK, CLUTCH SWITCH LEFT HEADLAMP M/T MAP SENSOR SHIELD MASS AIR FLOW SENSOR (SHIELD) MULTIPURPOSE CHECK CONNECTOR NCA WIRE NEUTRAL SWITCH PCB BLOCK FRONT WIPER (HIGH) RELAY PCM PDM (ACC) RELAY PDM OUTLET RELAY RIGHT HEADLAMP STOP LAMP SWITCH W/ EPB W/ ESC W/ SMART KEY W/O ESC WASHER LEVEL SENSOR WASHER MOTOR

2.0L BLK WIRE BLK/ORG WIRE CVVD ACTUATOR IGNITION COIL 1 IGNITION COIL 2 IGNITION COIL 3 IGNITION COIL 4 NEUTRAL SWITCH SPEED SENSOR SPEED SENSOR SHIELD TCM
