Supplemental restraints circuit, dual stage for Hyundai Accent II facelift (2002-2005)

BLK WIRE BLU WIRE BLU/BLK WIRE BLU/ORG WIRE BRN WIRE CRASH OUTPUT DASH FUSE BOX (BEHIND LEFT KICK PANEL) DATA LINK CONNECTOR (PARTIAL) (AT LOWER LEFT SIDE OF DASH) DRIVER SEAT BELT BUCKLE SWITCH VOLTAGE OUTPUT DRIVER SEAT BELT PRETENSIONER DRIVER SEAT TRACK POSITION SENSOR DRIVER SIDE AIR BAG FUSE 3 FUSE 4 GRN WIRE GRN/BLK WIRE GRN/ORG WIRE GRY WIRE GRY/BLK WIRE GRY/ORG WIRE HOT IN ON OR START INSTRUMENT CLUSTER K LINE LT GRN WIRE ORG/ WIRE ORG/BLK WIRE PASSENGER AIR BAG PASSENGER SEAT BELT BUCKLE SWITCH VOLTAGE OUTPUT PASSENGER SEAT BELT PRETENSIONER PASSENGER SEAT TRACK POSITION SENSOR PASSENGER SIDE AIR BAG PNK WIRE PNK/BLK WIRE RED WIRE RED/BLK WIRE RED/ORG WIRE SEAT TRACK SENSOR SEAT BUCKLE SWITCH SEAT BUCKLE SWITCH SEAT TRACK SENSOR SRS CONTROL MODULE (BELOW CENTER OF DASH, IN FRONT OF CONSOLE) SRS INDICATOR (AIR BAG) WHT WIRE WHT/ORG WIRE YEL WIRE YEL/BLK WIRE YEL/ORG WIRE

BLK WIRE BLU WIRE BLU/BLK WIRE BLU/ORG WIRE CLOCK- SPRING DRIVER AIR BAG DRIVER SATELLITE SENSOR (AT LEFT "B" PILLAR) DRIVER'S FRONT IMPACT SENSOR (AT LEFT FRONT OF ENGINE COMPARTMENT) ETACM (BEHIND DASH, LEFT OF STEERING COLUMN) GRN WIRE GRN/BLK WIRE GRY WIRE LT GRN WIRE MULTI- FUNCTION SWITCH NCA WIRE ORG/ WIRE PASSENGER SATELLITE SENSOR (AT RIGHT "B" PILLAR) PASSENGER'S FRONT IMPACT SENSOR (AT RIGHT FRONT OF ENGINE COMPARTMENT) STEERING WHEEL) TACM (BEHIND DASH, LEFT OF STEERING COLUMN) W/ ETACS W/ TACS WHT WIRE YEL/BLK WIRE YEL/ORG WIRE
