Car Wiring Diagrams for Instrument illumination circuit for Hyundai Accent II facelift (2002-2005)

A/C SWITCH A/T SHIFT LEVER ASHTRAY AUDIO BLK WIRE BLOWER SWITCH BULB TYPE CIGARETTE LIGHTER CONTROL DEFOGGER SWITCH DIGITAL CLOCK EL SHEET EL TYPE ETACM (BEHIND DASH, LEFT OF STEERING COLUMN) FRONT FOG LAMP SWITCH FRONT, REAR FRONT FUSIBLE LINK (LAMP) GRN WIRE GRN/BLK WIRE GRN/ORG WIRE HAZARD SWITCH HOT AT ALL TIMES ILLUM ILLUM (5 X) INSTRUMENT CLUSTER INVERTER JOINT JOINT CONNECTOR LEFT FRONT POWER WINDOW SWITCH LEFT REAR POWER WINDOW SWITCH LEFT T/LAMP FUSE LIGHT SWITCH MULTIFUNCTION SWITCH NCA WIRE OFF HEAD ORG/ WIRE PARK REAR WIPER/ WASHER SWITCH RED/BLK WIRE RHEOSTAT RIGHT REAR POWER WINDOW SWITCH TACM (BEHIND DASH, LEFT OF STEERING COLUMN) RIGHT FRONT POWER WINDOW SWITCH TAILLAMP RELAY W/ ETACS W/ TACS WHT WIRE
