Hyundai Accent II facelift (2002-2005) engine coolant temperature gauge micro computer Wiring diagram
This page shows the only wiring diagram for the component.engine coolant temperature gauge micro computer, which is found in the car Hyundai Accent II facelift (2002-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram engine coolant temperature gauge micro computer (1 of 1)
2 (1.5L)
3 (1.6L)
4 3 2 1 ACC/ON INPUT DIM INPUT MEMORY POWER GROUND
ABS INDICATOR
ANTI-LOCK BRAKES SYSTEM
AUDIO FUSE
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BLU/BLK WIRE
BRAKE FLUID LEVEL SENSOR (ON SIDE OF BRAKE MASTER CYLINDER)
BRAKE WARNING INDICATOR
BRN WIRE
BULB TYPE
CHARGE INDICATOR
DASH FUSE BOX (BEHIND LEFT KICK PANEL)
DIGITAL CLOCK
DOOR AJAR INDICATOR
EL SHEET
EL TYPE
ENGINE CONTROLS SYSTEM
ENGINE COOLANT TEMPERATURE GAUGE MICRO COMPUTER
FUEL GAUGE
FUEL GROUND
FUEL IND
FUEL LEVEL FLOAT
FUEL SENDER GAUGE SENDER
FUEL SENDER, FUEL PUMP MOTOR (IN FUEL TANK)
FULL EMPTY
FUSE 14
FUSE 2
GRN WIRE
GRN/BLK WIRE
GRN/ORG WIRE
GRY WIRE
GRY/BLK WIRE
GRY/ORG WIRE
HEADLIGHTS SYSTEM
HOT AT ALL TIMES
HOT IN ACC OR ON
HOT IN ON OR START
ILLUMINATION (5 BULBS)
IN AMBIENT
IN FUEL
IN TEMP
INDICATOR HIGH BEAM
INDICATOR LEFT TURN
INJECTION
INSTRUMENT CLUSTER
INVERTER
JOINT CONNECTOR
LOW FUEL INDICATOR
MALFUNCTION INDICATOR LAMP (CHECK ENGINE)
NCA WIRE
O/D OFF INDICATOR
OIL PRESSURE INDICATOR
OIL PRESSURE SWITCH (ON LEFT REAR SIDE OF ENGINE)
ON/START IN
ORG/ WIRE
ORG/BLK WIRE
PNK WIRE
RED/BLK WIRE
RED/ORG WIRE
RIGHT TURN INDICATOR
SEAT BELT INDICATOR
SIGNAL GROUND
SPEED IN VEHICLE
SRS INDICATOR
STARTING/ CHARGING SYSTEM
SUPPLEMENTAL RESTRAINTS SYSTEM
TACHO IN
TACHOMETER
TAILGATE AJAR TRUNK LID AJAR INDICATOR
TRANSMISSIONS SYSTEM
WARNING SYSTEM
WHT WIRE
YEL WIRE
YEL/ORG WIRE
Go to component -> Instrument cluster circuit (1 of 2) -> ENGINE COOLANT TEMPERATURE GAUGE MICRO COMPUTER
