Car Wiring Diagrams for Chime circuit for Hyundai Accent II (1999-2012)

2 11 12 20 DOOR SWITCH (ALL) DOOR SWITCH TAIL LAMP SW SIG GROUND 9 6 MEMORY POWER STEERING LOCK INPUT BCM (LEFT CENTER OF DASH) BLK WIRE BLU WIRE BLU/ORG WIRE BRN WIRE CANADA USA CHIME BELL (BEHIND RIGHT SIDE OF DASH) CHIME BELL CTRL CLUSTER FUSE DOOR OPEN IND DOOR WARNING SWITCH DRIVER DOOR SWITCH (ON LEFT "B" PILLAR) DRIVER SEAT BUCKLE SWITCH (UNDER SEAT) GRN WIRE GRY WIRE HOT AT ALL TIMES HOT IN ON OR START I/P JUNCTION BOX I/P-G I/P-J I/P-K I/P-N INSTRUMENT CLUSTER LIGHT SWITCH MULT B/UP FUSE MULTI- FUNCTION SWITCH NCA WIRE OFF ORG/ WIRE PARK HEAD PNK ON/START INPUT WIRE PNK WIRE POWER CONNECTOR RED WIRE SEAT BELT IND SEAT BELT SWITCH SEAT BELT SWITCH (UNDER DRIVER'S SEAT) WHT/BLK WIRE
