Hyundai Accent I (1994-2000) turn tail stop Wiring diagram
This page shows the only wiring diagram for the component.turn tail stop, which is found in the car Hyundai Accent I (1994-2000). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram turn tail stop (1 of 1)
BLK WIRE
DASH FUSE BOX (BELOW LEFT SIDE OF DASH, AT KICK PANEL)
DIGITAL CLOCK
FUSE 4
FUSIBLE LINK H
GRN WIRE
GRN/BLU WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HEAD
HEADLIGHTS SYSTEM (FRONT FOG- LAMP RELAY) (CANADA ONLY)
HEADLIGHTS SYSTEM (HEADLAMP SWITCH)
HIGH MOUNT STOP LAMP
HOT AT ALL TIMES
JOINT
LAMP
LEFT FRONT PARK/TURN SIGNAL LAMP
LEFT LICENSE
LEFT REAR COMBINATION LAMP
LEFT TAILLAMP FUSE
LIGHT SWITCH
MULTIFUNCTION SWITCH
NCA WIRE
OFF
PARK
PNK WIRE
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/YEL WIRE
RIGHT FRONT PARK/TURN SIGNAL LAMP
RIGHT LICENSE LAMP
RIGHT REAR COMBINATION LAMP
RIGHT TAILLAMP FUSE
STOP LAMP SWITCH (ON SUPPORT BRACKET)
TAIL STOP
TAILLAMP RELAY
TURN
TURN TAIL STOP
W/ DRL W/O DRL
WHT WIRE
YEL WIRE
Go to component -> Exterior lamps circuit (1 of 2) -> TURN TAIL STOP
