Hyundai Accent I (1994-2000) engine compartment relay and Wiring diagrams
This page contains all the electrical diagrams for the component. engine compartment relay and, in which he is found in the car Hyundai Accent I (1994-2000). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram engine compartment relay and (1 of 2)
10 8 (STD) (DLX)
A/C RELAY
BATTERY VOLTAGE GROUND
BLK WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU/BLK WIRE
BLU/RED WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BOX (AT LEFT KICK PANEL)
BRN WIRE
BRN/RED WIRE
BRN/WHT WIRE
CAMSHAFT POSITION (CMP) SENSOR (TOP REAR OF CYLINDER HEAD)
CAN CLOSE VALVE COND FAN REL CNTRL
CANISTER CLOSE VALVE (BEHIND LEFT SIDE OF FRONT BUMPER)
CANISTER PURGE CONTROL VALVE (LEFT SIDE OF ENGINE COMPT)
CHECK ENGINE IND
CKP SENSOR GROUND
COOLING FANS SYSTEM
CRANKSHAFT POSITION (CKP) SENSOR (LOWER LEFT SIDE OF ENGINE BLOCK)
DASH FUSE
ENGINE COMPARTMENT RELAY AND
ENGINE CONTROL MODULE (ECM) (BEHIND LEFT SIDE OF DASH)
ENGINE CONTROL RELAY (ABOVE LEFT KICK PANEL)
ENGINE RPM SIGNAL A/C RELAY CNTRL
FUEL PUMP MOTOR (IN TOP OF FUEL TANK)
FUEL PUMP RELAY
FUSE 10
FUSE 5
FUSE BOX (LEFT SIDE OF ENGINE COMPT)
FUSIBLE LINK I
GRN WIRE
GRN/RED WIRE
GRN/WHT WIRE
GROUND
HOT AT ALL TIMES
HOT IN ON OR START
IGNITION SIG (CYL 1,4) MEMORY POWER ENGINE CNTRL RELAY GROUND IDLE ACTR OPEN
IGNITION SIG (CYL 2,3)
INJ 3 CNTRL INJ 2 CNTRL
INSTRUMENT CLUSTER
LT GRN/BLK WIRE
LT GRN/WHT WIRE
LT GRN/YEL WIRE
M/T ONLY 16 17 18 19 20 21 22 23
MAF SENSOR GROUND
MALFUNCTION INDICATOR
NCA WIRE
PASSENGER COMPARTMENT RELAY BOX (LEFT SIDE OF STEERING COLUMN)
PCV CNTRL
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/YEL WIRE
TP SENSOR SIGNAL
WHT/BLK WIRE
WHT/BLU WIRE
WHT/RED WIRE
WHT/YEL WIRE
YEL/BLK WIRE
YEL/BLU WIRE
YEL/WHT WIRE
Go to component -> Wiring diagram engine performance 1.5l dohcs (1 of 3) -> ENGINE COMPARTMENT RELAY AND
