Hyundai Accent I (1994-2000) a/t and key lock control module Wiring diagrams
This page contains all the electrical diagrams for the component. a/t and key lock control module, in which he is found in the car Hyundai Accent I (1994-2000). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram a/t and key lock control module (1 of 2)
3 DOOR
4 DOOR
A/C SWITCH
A/T AND KEY LOCK CONTROL MODULE
A/T SHIFT LEVER SWITCH
AUDIO
BLK WIRE
BLK/WHT WIRE
BLOWER SWITCH
CIGARETTE LIGHTER
COURTESY LAMP
DATA LINK CONNECTOR
DIGITAL CLOCK
FLASH- ER UNIT
FRESH/RECIRC BUTTON AND BLOWER CONTROL PANEL ILLUMINATION
FROM JOINT CONNECTOR (DIAGRAM 1 OF 3)
FRONT FOG LAMP SWITCH
HEATER-A/C CONTROL PANEL
HIGH MOUNT STOP LAMP
HIGH MOUNTED STOP LAMP LEFT REAR COMBINATION LAMP
INSTRUMENT CLUSTER
INTERMITTENT WIPER TIMER MODULE
JOINT
JOINT CONNECTOR (BEHIND CENTER OF DASH)
LEFT FRONT DOOR SWITCH
LEFT LICENSE LAMP
LEFT REAR DOOR SWITCH REAR WIPER MOTOR FUEL SENDER
LIGHT SWITCH
MULTI- FUNCTION SWITCH
NCA WIRE
PASSENGER COMPARTMENT RELAY BOX (LEFT SIDE OF DASH)
POWER DOOR MIRROR SWITCH
POWER WINDOW MAIN SWITCH
POWER WINDOW RELAY
REAR DEFOGGER GLASS
REAR DEFOGGER SWITCH
REAR DEFOGGER TIMER
REAR WIPER/ WASHER SWITCH
RELAY (M/T)
RHEOSTAT
RIGHT LICENSE LAMP
RIGHT REAR COMBINATION LAMP
RIGHT REAR DOOR SWITCH RIGHT FRONT DOOR SWITCH
ROTARY TYPE ONLY
SEAT BELT SWITCH
SEAT BELT TIMER
THERMO- STATIC SWITCH
WHT WIRE
WIPER/ WASHER SWITCH
Go to component -> Ground distribution circuit (2 of 3) -> A/T AND KEY LOCK CONTROL MODULE
Wiring diagram a/t and key lock control module (2 of 2)
3 DOOR ONLY
A/T
A/T AND KEY LOCK CONTROL MODULE
A/T SHIFT LEVER
AUDIO
BLK WIRE
BLOWER RELAY
BLU WIRE
BLU/GRN WIRE
BLU/RED WIRE
BLU/WHT WIRE
CIGAR- ETTE LIGHTER
COURTESY LAMP
DASH FUSE BOX
DATA LINK CONNECTOR (DLC)
DIGITAL CLOCK
DOOR AJAR IND
DOOR WARNING SWITCH
ENGINE COMPARTMENT FUSE/RELAY BOX
ENGINE CONTROL MODULE (ECM)
FROM FUSIBLE LINK B (ENGINE COMPT FUSE/RELAY BOX) (DIAGRAM 1 OF 4)
FROM IGNITION SWITCH (HOT IN ACC OR ON) (DIAGRAM 1 OF 4)
FROM IGNITION SWITCH (HOT IN ON) (DIAGRAM 1 OF 4)
FRONT WIPER MOTOR FRONT WASHER MOTOR
FUSE 13
FUSE 14
FUSE 15
FUSE 16
FUSE 3
FUSE 4
FUSE 5
FUSE 6
FUSE 7
FUSE 8
GRN WIRE
HAZARD SWITCH
HEAD- LAMP RELAY
INSTRUMENT CLUSTER
INTERMIT- TENT WIPER TIMER
KEY INTERLOCK SOLENOID
LT GRN WIRE
NCA WIRE
PASSENGER COMPARTMENT FUSE/RELAY BOX
POWER DOOR MIRROR SWITCH
POWER WINDOW RELAY
REAR DEFOGGER TIMER
REAR WASHER MOTOR REAR WIPER MOTOR
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
STOP LAMP SWITCH
TRANSAXLE CONTROL MODULE (TCM)
TRUNK LAMP
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (2 of 4) -> A/T AND KEY LOCK CONTROL MODULE
