Ignition lock solenoid circuit for Hummer H3 I (2005-2010)
Ignition lock solenoid circuit
AUTOMATIC TRANSMISSION SHIFT LEVER
BLK WIRE
BODY CONTROL MODULE (BCM) (BEHIND RIGHT FRONT KICK PANEL)
DK BLU WIRE
GRY WIRE
HOT AT ALL TIMES
IGNITION LOCK CYLINDER CONTROL ACTUATOR (ON UPPER RIGHT SIDE OF STEERING COLUMN)
PARK POSITION SWITCH (CLOSED IN PARK)
RAP RELAY
RAP/ACCY RELAY 88
S/ROOF FRT/WPR FUSE 9
UNDERHOOD FUSE BLOCK (ABOVE LEFT FRONT WHEELWELL)
YEL WIRE
