Electrochromic mirror circuit for Hummer H3 I (2005-2010)
Electrochromic mirror circuit
AMBIENT AIR TEMP SENSOR LOW REF
AMBIENT AIR TEMPERATURE SENSOR (ATTACHED TO FRONT CENTER OF RADIATOR SUPPORT)
BARE
BLK WIRE
BLK/GRN WIRE
BLK/GRY WIRE
BLK/WHT WIRE
BRN WIRE
BRN/WHT WIRE
CRUISE/ MISC FUSE 35
DK BLU/WHT WIRE
DK GRN WIRE
DK GRN/WHT WIRE
EMERGENCY SWITCH
GREEN LED
HOT AT ALL TIMES
HOT IN RUN OR START UNDERHOOD FUSE BLOCK (ABOVE LEFT FRONT WHEELWELL)
IGN
INSIDE REARVIEW MIRROR
KEYPAD CTRL
KEYPAD GREEN LED SIG
KEYPAD RED LED SIG WIRE
LOGIC
LT BLU WIRE
LT GRN/BLK WIRE
NAVIGATION SYSTEM
ONSTAR BUTTON ASSEMBLY
ONSTAR SWITCH
PHONE SWITCH
RED LED WIRE
RUN/ CRNK RELAY 78
SIG KEYPAD
SUPPLY VOLT
YEL WIRE
YEL/BLK WIRE
