Hummer H3 I (2005-2010) Computer data lines circuit

15 16 PPL PPL CLASS 2 SERIAL DATA CLASS 2 SERIAL DATA 53 33 HI SPD SERIAL DATA BUS + HI SPD SERIAL DATA BUS - A/T AUX PWR 1 FUSE 51 BLK WIRE BLK/WHT WIRE BODY CONTROL MODULE (BCM) (BEHIND RIGHT FRONT KICK PANEL) CIGAR LIGHTER DATA LINK CONNECTOR (DLC) (LEFT SIDE OF DASH) DATA LINK RESISTOR DIGITAL RADIO RECEIVER (RIGHT SIDE OF DASH) ELECTRONIC BRAKE CONTROL MODULE (EBCM) (LEFT OF MASTER CYLINDER) ENGINE CONTROL MODULE (ECM) (RIGHT REAR CORNER OF ENGINE COMPT) GENERATOR BATTERY CONTROL MODULE (LEFT FRONT OF ENGINE COMPT, NEAR BATTERY) HOT AT ALL TIMES INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE (SDM) (BENEATH LOWER CONSOLE) INSTRUMENT PANEL CLUSTER (IPC) M/T ORG/ WIRE PPL PPL CLASS 2 SERIAL DATA PPL PPL 11 10 CLASS 2 SERIAL DATA CLASS 2 SERIAL DATA PPL PPL 1807 1807 CLASS 2 SERIAL DATA CLASS 2 SERIAL DATA RADIO TAN WIRE TAN/WHT WIRE THEFT DETERRENT MODULE (TDM) TRANSFER CASE SHIFT CONTROL MODULE (BEHIND GLOVE BOX) TRANSMISSION CONTROL MODULE (TCM) UNDERHOOD FUSE BLOCK (ABOVE LEFT FRONT WHEELWELL)
