Hummer H3 I (2005-2010) trlr bck/up fuse 42 Wiring diagram
This page shows the only wiring diagram for the component.trlr bck/up fuse 42, which is found in the car Hummer H3 I (2005-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram trlr bck/up fuse 42 (1 of 1)
BACKUP LAMPS CIRCUIT
BLK WIRE
BLU WIRE
BLUNT CUT)
BRN WIRE
DK BLU WIRE
DK DK DK
DK GRN WIRE
E-BRAKE FUSE 83
GRILLE GUARD FUSE 2
GRILLE LAMPS RELAY (BELOW SIDE AIR INLET COVER)
GRN WIRE
HOT AT ALL TIMES
LEFT OFF ROAD GRILLE LAMP
LEFT OFF ROAD ROOF LAMP
LT BLU WIRE
LT GRN WIRE
LT LT
OFF ROAD GRILLE LAMP SWITCH
OFF ROAD ROOF LAMP SWITCH
OFF ROAD ROOF LAMPS RELAY (BELOW SIDE AIR INLET COVER)
ORG/ WIRE
RAP/ACCY RELAY 88
RED WIRE
RIGHT OFF ROAD GRILLE LAMP
RIGHT OFF ROAD ROOF LAMP
ROOF LP FUSE 4
SPO FUSE 10
TRAILER PROVISION (BLUNT CUT)
TRLR B+ FUSE 84
TRLR BCK/UP FUSE 42
UNDERHOOD FUSE BLOCK (ABOVE LEFT FRONT WHEELWELL)
W/ OFF ROAD RADIATOR GRILLE GUARD LAMP, DEALER INSTALLED
W/ ROOF MOUNTED OFF ROAD LAMP, DEALER INSTALLED
W/ TRAILER CONNECTOR W/O TRAILER CONNECTOR
WHT WIRE
YEL WIRE
Go to component -> Exterior lamps circuit (3 of 3) -> TRLR BCK/UP FUSE 42
