Hummer H3 I (2005-2010) s/roof frt/wpr fuse 9 Wiring diagrams
This page contains all the electrical diagrams for the component. s/roof frt/wpr fuse 9, in which he is found in the car Hummer H3 I (2005-2010). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram s/roof frt/wpr fuse 9 (1 of 3)
BLK WIRE
BODY CONTROL MODULE (BEHIND RIGHT FRONT KICK PANEL)
BRN WIRE
DK GRN WIRE
FRT/WPR FUSE 6
GRY WIRE
HI LO
HI/LOW WPR RELAY 73
HOT AT ALL TIMES
LT BLU WIRE
MIST
NCA WIRE
OFF
OFF INT
ON/OFF WPR RELAY 72
PARK OUT
PPL
RAP RELAY COIL CONTROL
RAP/ACCY RELAY 88
RED WIRE
S/ROOF FRT/WPR FUSE 9
TURN SIGNAL/ MULTI-FUNCTION SWITCH
UNDERHOOD FUSE BLOCK (ABOVE LEFT FRONT WHEELWELL)
WINDSHIELD WASHER FLUID PUMP (MOUNTED ON FLUID RESERVOIR)
WINDSHIELD WASHER PUMP CONTROL
WINDSHIELD WIPER MOTOR (UNDER CENTER OF FRONT COWLING)
WINDSHIELD WIPER MOTOR PARK SWITCH SIGNAL
WINDSHIELD WIPER SWITCH SIGNAL 1
WINDSHIELD WIPER SWITCH SIGNAL 2
WINDSHIELD WIPER/ WASHER SWITCH
WIPER DIODE
YEL WIRE
Go to component -> Front wiper/washer circuit -> S/ROOF FRT/WPR FUSE 9
Wiring diagram s/roof frt/wpr fuse 9 (2 of 3)
AUTOMATIC TRANSMISSION SHIFT LEVER
BLK WIRE
BODY CONTROL MODULE (BCM) (BEHIND RIGHT FRONT KICK PANEL)
DK BLU WIRE
GRY WIRE
HOT AT ALL TIMES
IGNITION LOCK CYLINDER CONTROL ACTUATOR (ON UPPER RIGHT SIDE OF STEERING COLUMN)
PARK POSITION SWITCH (CLOSED IN PARK)
RAP RELAY
RAP/ACCY RELAY 88
S/ROOF FRT/WPR FUSE 9
UNDERHOOD FUSE BLOCK (ABOVE LEFT FRONT WHEELWELL)
YEL WIRE
Go to component -> Ignition lock solenoid circuit -> S/ROOF FRT/WPR FUSE 9
Wiring diagram s/roof frt/wpr fuse 9 (3 of 3)
BLK WIRE
BODY CONTROL MODULE (BCM) (BEHIND RIGHT FRONT KICK PANEL)
BRN WIRE
GROUND
GRY WIRE
HOT AT ALL TIMES
IGN VOLT
LOGIC
ORG/ WIRE
PWR S/ROOF FUSE 57
RAP RLY
RAP/ACCY RELAY 88
S/ROOF FRT/WPR FUSE 9
SUNROOF ACTUATOR MOTOR
SUNROOF MOTOR (AT FRONT OF SUNROOF MODULE)
SUNROOF SWITCH
SW CLOSED
SW OPEN
UNDERHOOD FUSE BLOCK (ABOVE LEFT FRONT WHEELWELL)
YEL WIRE
Go to component -> Power top/sunroof circuit -> S/ROOF FRT/WPR FUSE 9
