Hummer H3 I (2005-2010) passenger heated seat circuit Wiring diagram
This page shows the only wiring diagram for the component.passenger heated seat circuit, which is found in the car Hummer H3 I (2005-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram passenger heated seat circuit (1 of 1)
BLK WIRE
BLK/RED WIRE
BODY CONTROL MODULE (BCM) (BEHIND RIGHT FRONT KICK PANEL)
BRN WIRE
DRIVER BACK HEATED SEAT ELEMENT (IN DRIVER SEAT BACK)
DRIVER CUSHION HEATED SEAT ELEMENT (IN DRIVER SEAT BOTTOM)
DRIVER HEATED SEAT MODULE (IN DRIVER SEAT BOTTOM)
DRIVER SEAT LUMBAR ADJUSTER SWITCH
HIGH/LOW STATUS IND BULB
HOT AT ALL TIMES
HTD/SEATS FUSE 1
HVAC RELAY 87
IGN 3 RLY COIL
LOW HIGH
NCA WIRE
ORG/ WIRE
PASSENGER HEATED SEAT CIRCUIT
PNK WIRE
PWR HTR SWITCH FUSE 53
RED WIRE
RED/BLK WIRE
UNDERHOOD FUSE BLOCK (ABOVE LEFT FRONT WHEEL WELL)
WHT WIRE
YEL WIRE
Go to component -> Driver heated seat circuit -> PASSENGER HEATED SEAT CIRCUIT
