Hummer H3 I (2005-2010) frt trn/ hazrd/ctsy mir fuse 56 Wiring diagram
This page shows the only wiring diagram for the component.frt trn/ hazrd/ctsy mir fuse 56, which is found in the car Hummer H3 I (2005-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram frt trn/ hazrd/ctsy mir fuse 56 (1 of 1)
AUTO
BLK WIRE
BLU WIRE
BODY CONTROL MODULE (BCM) (BEHIND RIGHT FRONT KICK PANEL)
BRN WIRE
BRN/WHT WIRE
BULB OUT
CENTER HIGH MOUNTED STOP LAMP (CHMSL)
DEALER INSTALLED
DIMM SW SIG HAZ SW SIG LOW REF PRK LMP SW TRN SIG SW
DK BLU WIRE
DK GRN WIRE
FRT TRN/ HAZRD/CTSY MIR FUSE 56
FRT/PRK FUSE 43
GRN WIRE
GRY WIRE
HAZARD SWITCH
HEADLAMP SWITCH
HOT AT ALL TIMES
LEFT
LEFT FRONT MARKER LAMP
LEFT FRONT PARK/ TURN SIGNAL LAMP
LR PRK LP RAP RLY CNTRL
LT BLU WIRE
OFF PPL
ON PARK
ORG/ WIRE
PEDAL ASSEMBLY)
PPL
PRK LMP RLY
PRK/LP RELAY 89
REAR TRN/ HAZRD FUSE 20
RED WIRE
RIGHT
RIGHT FRONT MARKER LAMP
RIGHT FRONT PARK/ TURN SIGNAL LAMP
STOP FUSE 54
STOP LAMP SWITCH (ABOVE BRAKE
STP LP VOLT
TO LR PRK FUSE 37 (DIAGRAM
TURN SIGNAL/ MULTI-FUNCTION SWITCH
TURN SWITCH
UNDERHOOD FUSE BLOCK (ABOVE LEFT FRONT WHEELWELL)
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Exterior lamps circuit (1 of 3) -> FRT TRN/ HAZRD/CTSY MIR FUSE 56
