Hummer H3 I (2005-2010) batt pos vol field duty cycle sig batt pos vol turn on sig 23 3140 225 Wiring diagram
This page shows the only wiring diagram for the component.batt pos vol field duty cycle sig batt pos vol turn on sig 23 3140 225, which is found in the car Hummer H3 I (2005-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram batt pos vol field duty cycle sig batt pos vol turn on sig 23 3140 225 (1 of 1)
BATT POS VOL FIELD DUTY CYCLE SIG BATT POS VOL TURN ON SIG 23 3140 225
BATTERY
BLK WIRE
BLK/WHT WIRE
CHARGE INDICATOR
CLASS 2 SERIAL DATA
CLSTR FUSE 19
COMPUTER DATA LINES SYSTEM
CONTROL REGULATOR
CYCLE SIG
DRIVER INFORMATION CENTER (DIC)
ENGINE CONTROL MODULE (ECM) (RIGHT REAR CORNER OF ENGINE COMPT)
FIELD DUTY GENERATOR
GENERATOR
GENERATOR BATTERY CONTROL MODULE (LEFT FRONT OF ENGINE COMPT, NEAR BATTERY)
GND REG CONTRL CLASS 2 SERIES DATA 5428 1807 PPL PPL
GRY WIRE
LOGIC INSTRUMENT PANEL CLUSTER (IPC)
MEGA FUSE FUSE 91
ORG/ WIRE
PPL
RED WIRE
RVC PWR FUSE 7
RVC VSENSE+ FUSE 32
SERIAL DATA
STARTER POWER DISTRIBUTION SYSTEM
UNDERHOOD FUSE BLOCK (ABOVE LEFT FRONT WHEELWELL)
USED) (NOT
VOLT GAUGE SERIAL DATA
Go to component -> Charging circuit -> BATT POS VOL FIELD DUTY CYCLE SIG BATT POS VOL TURN ON SIG 23 3140 225
