Rear heated seats circuit for Hummer H2 I facelift (2007-2009)

1 2 3 4 5 6 7 8 B+ GND BACK CUSHION IND BACK IND BACK SWITCH BACK/ CUSHION SWITCH BLK WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DK BLU WIRE DK GRN WIRE GND ELEMENT CTRL GND ELEMENT CTRL PNK WIRE HOT AT ALL TIMES I/P FUSE BLOCK (ON LOWER LEFT SIDE OF I/P, BEHIND ACCESS PANEL) LEFT REAR CUSHION HEATED SEAT ELEMENT (UNDER RIGHT REAR SEAT CUSHION UPHOLSTERY) LOGIC REAR SEAT AUDIO (RSA) CONTROL LOW REF LT BLU WIRE NCA WIRE ORG/ WIRE PNK WIRE REAR HEATED SEAT CONTROL MODULE (UNDER FRONT OF LEFT REAR SECOND ROW SEAT) REAR SEAT FUSE RED/WHT WIRE RIGHT REAR CUSHION HEATED SEAT ELEMENT (UNDER LEFT REAR SEAT CUSHION UPHOLSTERY) SENS SIG SERIAL DATA WHT/BLK WIRE
