Computer data lines circuit for Hummer H2 I facelift (2007-2009)
Computer data lines circuit (1 of 2)
AUDIO AMPLIFIER (UNDER FRONT FLOOR CONSOLE, BETWEEN FRONT SEATS)
DIGITAL RADIO RECEIVER (BEHIND GLOVE BOX)
DK GRN WIRE
DRIVER DOOR/LOCK WINDOW SWITCH
HOT AT ALL TIMES
HVAC CONTROL MODULE
I/P FUSE BLOCK (ON LOWER LEFT SIDE OF DASH, BEHIND ACCESS PANEL)
INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE (SDM) (UNDER LEFT FRONT SEAT)
INSTRUMENT PANEL CLUSTER (IPC)
LO GMLAN SERIAL DATA
LTR FUSE 44
MEMORY SEAT MODULE (MSM) (UNDER DRIVER SEAT)
NCA WIRE
PASSENGER DOOR LOCK/ WINDOW SWITCH
POWER DISTRIBUTION SYSTEM
RADIO
REAR HEATED SEAT CONTROL MODULE (UNDER FRONT OF LEFT REAR SECOND ROW SEAT)
REAR SEAT AUDIO (RSA) CONTROL (AT REAR OF CENTER CONSOLE)
RED/WHT WIRE
RIGHT I/P JUNCTION BLOCK (RIGHT SIDE OF DASH BEHIND END TRIM PANEL)
UNDERHOOD FUSE BLOCK (AT LEFT SIDE OF ENGINE COMPT, NEAR BATTERY)
W/ HEAD CURTAIN AIR BAG
W/ ONSTAR, DIGITAL RADIO
W/O ONSTAR, DIGITAL RADIO
Computer data lines circuit (2 of 2)
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (BCM)
DATA COMMUNICATION
DK GRN WIRE
HI SER DATA BUS+
LO GMLAN SER DATA
LO GMLAN SERIAL DATA
LT BLU WIRE
RED/WHT WIRE
SER DATA COMM
TAN WIRE
TAN/BLK WIRE
TRANSFER CASE SHIFT CONTROL MODULE (BEHIND HEADLIGHT SWITCH)
TRANSMISSION CONTROL MODULE (TCM) (PART OF AUTOMATIC TRANSMISSION)
W/ OFF ROAD SUSPENSION CHASSIS PACKAGE
W/ ONSTAR
W/O OFF ROAD SUSPENSION CHASSIS PACKAGE
W/O ONSTAR
